SL260
Unmatched Production
The SL260 is a titan of production capabilities. Create a true main stage with an amazing viewing experience for the whole crowd. With even more lifting and rigging capacity and stage extension options, the SL260 can support your most ambitious productions while still providing the highest level of safety offered in the industry.
Technical SpecsSpecifications
.01
Length + Depth
32' x 24'
.02
Height from Ground
3'6"–5'3"
.03
Integrated Roof Height from Deck (Inclined roof)
20'–17'9"
.04
Flown Sound Capacity
2,500 lbs per side
.05
Roof Lifting Capacity
12,000 lbs
.06
Overhead Clearance Once Built
24'–40'6"
.07
Roof Load Bearing Capacity
18,500 lbs
.08
Min. Base Stage Set-Up Time
2 hrs
including time for landing and leveling
.09
Min. Number of Stage Technicians
2
.10
Mode of Transportation
1 tractor trailer
.11
Required Overhead Clearance for Travel
13'4"
.12
Gust Wind Resistance
77 mph w/ windwalls; 115 mph w/out windwalls
.13
Wind Wall Coverage
Full-Width Back Wall in Vinyl and Full-Depth Side Walls in Vinyl
full covered side wing
